| Model | TL254 | ||
| Type | 4x4 | ||
| Machine parameters | PTO power (KN) | 15.6 | |
| Rated Traction( KN) | 5.9 | ||
| Dimensions(mm) | 3220×1455×2025 | ||
| Wheelbase（mm） | 1730 | ||
| Track(mm) | Front wheel | 1225-1425 | |
| Rear wheel | 1160-1300 | ||
| Minimum ground clearance(mm) | 280 | ||
| Turning circle radius | Unilateral braking | 2.3 | |
| Not unilateral braking | 3 | ||
| Weight (KG) | 1402 | ||
| Drive Train | Clutch | Single stage cluth | |
| Gearbox | 8+2 shift | ||
| Walking steering | Tire | Front wheel | 6.5-16 |
| Rear wheel | 11.2-24 | ||
| Braking system | Service brake | Mechanical hoof type | |
| Parking brake | Locking pedal type | ||
| Working equipment | Maximum lifting force at 610mm(KN) | 4.96 | |
| Suspension mechanism | Three-point suspension type 1 | ||
| PTO shaft | PTO speed r/min | 540/760 | |
| Engine | Engine brand | YTO | |
| Engine type | Diesel engine | ||
| Engine cylinder | 3 | ||
| Start | Start method | Electric | |
| Main fill volume (L) | Radiater | 10 | |
| Fuel tank | 21 | ||
| Engine sump | 3.5 | ||
| Gearbox oil | 11 | ||
| Lifter | 9 | ||
| Rated Power (HP) | 25HP |
| Type | Wheel Tractor |
| Place of Origin | Shandong, China |
| Warranty | 2 years |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 2 years |
| Core Components | Motor, Pump, Pressure vessel, Gearbox, Engine, Gear, PLC, Bearing |
| Engine Brand | Yangdong/Laidong/Xichai/Sida |
| Weight | 1800 KG |
| By wheel | 4WD |
| Use | Farm Tractor |
| Drive Type | Gear Drive |
| Brand Name | TAVOL |
| Key Selling Points | High Safety Level |
| Product name | farm tractor 4x4 25hp Tractor for small farm china mini tractor |
| Engine Emission | Euro2/Euro3 |
| Engine type | 3cylinder diesel |
| Clutch | Single Or Dual- Stage Clutch |
| PTO Speed | 540/760 r/min |
| Transmission | Gear box |
| Steering | Hydraulic Steering |
| Linkage | 3-point |
| Tire | 6.5-16/11.2-24 |
| Differential lock | Yes |
| Packaging and delivery | |
| Selling Units: | Single item |
| Single package size: | 340X170X170 cm |
| Single gross weight: | 1400.000 kg |
