Taishan-400D
|
Rated power kW: |
29.4 |
|
Type |
4×2 wheeled |
|
Overall dimensions (length x width x height) (mm) |
3000×1320×2150 |
|
Wheelbase (mm) |
1750 |
|
Wheelbase (front/rear) mm: |
950-1050/910-1060 |
|
Rated traction force kN |
≧7.4 |
|
Minimum use mass kg |
1230 |
|
Number of gears/(minimum speed ~ maximum speed/km/h) |
8+2/1.45～22.08 |
|
Tire specifications (front/rear) |
6.00-12/9.5-16 |
|
Maximum lifting force kN |
≥6.8 |
Taishan-404D
|
Rated power kW: |
29.4 |
|
Type |
4×4 wheeled |
|
Overall dimensions (length x width x height) (mm) |
3100×1320×2150 |
|
Wheelbase (mm) |
1850 |
|
Wheelbase (front/rear) mm: |
1050/1060 |
|
Rated traction force kN |
≧8.4 |
|
Minimum use mass kg |
1330 |
|
Number of gears/(minimum speed ~ maximum speed/km/h) |
8+2/1.45～22.08 |
|
Tire specifications (front/rear) |
6.00-12/9.5-16 |
|
Maximum lifting force kN |
≥6.8 |
Taishan-450D
|
Rated power kW: |
33.1 |
|
Type |
4×2 wheeled |
|
Overall dimensions (length x width x height) (mm) |
3000×1320×2150 |
|
Wheelbase (mm) |
1750 |
|
Wheelbase (front/rear) mm: |
1050/1060 |
|
Rated traction force kN |
≧7.8 |
|
Minimum use mass kg |
1230 |
|
Number of gears/(minimum speed ~ maximum speed/km/h) |
8+2/1.39～21.16 |
|
Tire specifications (front/rear) |
4.50-12/9.5-16 |
|
Maximum lifting force kN |
≥7.7 |
Taishan-454D
|
Rated power kW: |
33.1 |
|
Type |
4×4 wheeled |
|
Overall dimensions (length x width x height) (mm) |
3100×1320×2150 |
|
Wheelbase (mm) |
1850 |
|
Wheelbase (front/rear) mm: |
1050/910-1060 |
|
Rated traction force kN |
≧8.6 |
|
Minimum use mass kg |
1330 |
|
Number of gears/(minimum speed ~ maximum speed/km/h) |
8+2/1.33～22.08 |
|
Tire specifications (front/rear) |
6.00-12/9.5-16 |
|
Maximum lifting force kN |
≥7.7 |
