| Model | TAVOL-1304 | |
| Machine parameters | Type | 4*4 |
| Rated Traction( KN) | 23.7 | |
| PTO Max Power (KW) | 65.6 | |
| Dimensions(mm) | 4805*2290*3055 | |
| Wheelbase(mm) | 2366 | |
| Track(mm) | Front wheel(mm) | 1790~1890 |
| Front wheel adjustment method | Not adjustable | |
| Rear wheel(mm) | 1630~2230 | |
| Rear wheel adjustment method | Adjustable | |
| Ground clearance(mm) | Minimum ground clearance(mm) | 480 |
| Minimum turning cricle radius | Use unilateral braking | 4.2±0.3 |
| Not unilateral braking | 4.9±0.3 | |
| Minimum use quality | 3855 | |
| Mass distribution(KG) | Rear wheel(KG) | 2405 |
| Drive Train | Clutch | Single plate,dry type double acting clutch |
| Working equipment | Maximum lifting force at 610mm(KN) | ≥20 |
| Suspension mechanism | Three-point suspension type 2 | |
| PTO shaft | PTO Speed(r/min) | 540/760 or 540/1000 or 760/1000 |
| Tire | Front wheel specifications | 11.2-24/12.4-24 |
| Rear wheel specifications | 13.6-38/18.4-30/16.9-34 | |
| Engine | 4 cylinders diesel engine | |
| Perfusion volume | Heat sink(L) | 14 |
| Fuel tank(L) | 145 | |
| Engine oil pan(L) | Accoding to the engine manual | |
| Rated Power (HP) | 130hp |
| Type | Wheel Tractor |
| Place of Origin | Shandong, China |
| Warranty | 2 YEAR |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 2 years |
| Core Components | Motor, Pump, Pressure vessel, Gearbox, Engine, Gear, PLC, Bearing |
| Engine Brand | YTO |
| Weight | 5000 KG |
| By wheel | 4WD |
| Use | Farm Tractor |
| Drive Type | Gear Drive |
| Brand Name | TAVOL |
| Key Selling Points | High Safety Level |
| Product name | Agriculture Machinery & Equipment 130hp farming wheel tractor price |
| Engine | YTO |
| Engine type | 4 cylinder |
| Clutch | Dual- Stage Clutch |
| PTO Speed | 540/1000r/min |
| Color | Customer Requirements |
| Dimension(L*W*H) | 4020*1820*2600 |
| Implements | Tiller |
| Tire | 8.3-24/14.9-30 |
| Model | TAVOL1004 |
| Packaging and delivery | |
| Packaging Details | Full Containers |
| Port | QINGDAO/TIANJIN/SHANGHAI |
| Supply Ability | |
| Supply Ability | 50 Set/Sets per Month |
