| Tavol 45hp Tactor Main Parameters | |||
| Model | TL454 | ||
| Type | 4x4 | ||
| Machine parameters | PTO power (KN) | 28.1 | |
| Rated Traction( KN) | 6.5 | ||
| Dimensions(mm) | 3300*1440*1870 | ||
| Wheelbase(mm) | 1975 | ||
| Track(mm) | Front wheel | 1225-1425 | |
| Rear wheel | 1160-1300 | ||
| Minimum ground clearance(mm) | 290 | ||
| Turning circle radius | Unilateral braking | 2.3 | |
| Not unilateral braking | 3 | ||
| Weight (KG) | 1402 | ||
| Drive Train | Clutch | Single stage cluth | |
| Gearbox | 8+2 shift | ||
| Walking steering | Tire | Front wheel | 6.00-16/6.5-16 |
| Rear wheel | 9.4-24/11.2-24 | ||
| Braking system | Service brake | Wet, disc, hydrostatic | |
| Parking brake | Independent hand brake | ||
| Working equipment | Maximum lifting force at 610mm(KN) | 6.64 | |
| Suspension mechanism | Three-point suspension type 1 | ||
| PTO shaft | PTO speed r/min | 540/760 | |
| Engine | Engine brand | XICHAI | |
| Engine type | Diesel engine | ||
| Engine cylinder | 4 | ||
| Start | Start method | Electric | |
| Main fill volume | Radiater | 10 | |
| Fuel tank | 29 | ||
| Engine oil pan(L) | 5 | ||
| Driveline oil (L) | 20 | ||
| Lifter(L) | 9.5 | ||
| This parameter table is for reference only, everything is based on actual products | |||
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 2 years |
| Core Components | Motor, Pump, Pressure vessel, Gearbox, Engine, Gear, PLC, Bearing |
| Engine Brand | LD/LC/XC |
| Weight | 1600 KG |
| By wheel | 4WD |
| Use | Farm Tractor |
| Drive Type | Gear Drive |
| Brand Name | TAVOL |
| Key Selling Points | High Safety Level |
| Horse power | 25-240hp |
| Engine Emission | Euro2/ Euro3 |
| Engine type | 4 cylinder diesel |
| Clutch | Single Or Dual- Stage Clutch |
| PTO Speed | 540/760rpm 540/1000rpm(Optional) |
| Transmission | Gear box |
| Steering | Hydraulic Steering |
| Linkage | 3 point |
| Tire | 9.5-24/11.2-24/11.2-28 |
| Differential lock | Yes |
