| Tavol 80hp Tactor Main Parameters | |||
| Model | TL804B | ||
| Type | 4x4 | ||
| Machine parameters | PTO power (KN) | 50 | |
| Rated Traction( KN) | 12.2 | ||
| Dimensions(mm) | 3560*1900*2650 | ||
| Track(mm) | Front wheel | 1320-1360mm | |
| Rear wheel | 1200-1600mm | ||
| Minimum ground clearance(mm) | 320 | ||
| Turning circle radius | Unilateral braking | 3.8卤0.30 | |
| Not unilateral braking | 4.3卤0.30 | ||
| Drive Train | Clutch | Dual stage clutch | |
| Gearbox | 12+12 shuttle shift | ||
| Walking steering | Tire | Front wheel | 9.5-24 |
| Rear wheel | 14.9-30 | ||
| Working equipment | Maximum lifting force at 610mm(KN) | 12.4 | |
| Suspension mechanism | Three-point suspension type 1 or 2 | ||
| Hydraulic output | Optional 1 or 2 groups | ||
| PTO shaft | PTO speed r/min | 540/760(optional:540/1000, 760/1000) | |
| Engine | Engine brand | Yunnei | |
| Engine type | Diesel engine | ||
| Engine cylinder | 4 | ||
| Optional | Cabin | Heater | |
| Start | Start method | Electric | |
| This parameter table is for reference only, everything is based on actual products | |||
| Rated Power (HP) | 85HP |
| Type | Wheel Tractor |
| Place of Origin | Shandong, China |
| Warranty | 2 years |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 2 years |
| Core Components | Motor, Gearbox, Engine |
| Engine Brand | Xinchai/YTO/weichai |
| Weight | 1500 KG |
| By wheel | 4WD |
| Use | Farm Tractor |
| Drive Type | Gear Drive |
| Brand Name | Tavol |
| Key Selling Points | Multifunctional |
| Engine type | Diesel 4 cylinders |
| Horse power | 85hp |
| Engine | Yunnei/YTO |
| PTO Speed | 540/760/1000r/min |
| Transmission | Gearbox |
| Tire | 9.5-24/14.9-30 |
| Clutch | Dual- Stage Clutch |
| Gear shift | 12+12 |
| Differential Lock | Yes |
| Steering type | Hydraulic |
| Packaging and delivery | |
| Packaging Details | CKD Packing or Full containers |
| Supply Ability | |
| Supply Ability | 500 Set/Sets per Month |
Main application
Customer site application: It is widely used for ploughing, rotary-cultivating, sowing, irrigation, spraying, harvesting and transportation etc. In paddy fields, dry land, arid land, orchard and plastic greenhouse fram tractor is 3-point suspension /attachement can work with Disc Plough, Disc plow, Rotary tiller Farrow plough. Cultivator ,and corn planter, Harvester ,Mower ,farm trailer etc
