| Tractor Parameters | Model | TY354 | |
| Drive Type | 4WD | ||
| Overall Dimensions L*W*H (mm): | 2810X1260X1230 | ||
| Wheel Track (mm) | Front | 1215 | |
| Rear | 1170-1370 | ||
| Wheel Base (mm) | 1760 | ||
| Ground Clearance (mm) | Under Front Axle | 310 | |
| Under Rear Axle | 310 | ||
| Rated Traction Force (KN) | 7.84 | ||
| Construction Mass (kg) | 1558 | ||
| Min. Turning Radius (m) | 3.8 | ||
| Theoretical | Forward | 1.78-27.38 | |
| Speed (km/h) | Reverse | 2.30-11.25 | |
| Engine Specification | Model | FAW-Xichai | |
| Type | 4-cylinder, Upright inline cylinder, radiator cooling, 4-stroke cycle, direct-injection | ||
| Rated Power (kW/hp) | 25.7/ 35 | ||
| Rated Speed (rpm) | 2300 | ||
| Bore*Stroke (mm) | 85x95 | ||
| Total Displacement (L) | 2.156 | ||
| Drive | Clutch | single-action , dry constant meshing | |
| System | Gear Box | 2*(4+1) sliding gear shift | |
| Main Drive | One Pair of Spiral Bevel Gears | ||
| Differential | Bevel Gear | ||
| Differential Lock | Sliding pin, foot operated | ||
| Final Transmissions | Gear transmission | ||
| Traveling Mechanism | Tire | Front | 6.5-16 |
| Rear | 9.50-24 | ||
| Steering Gear | Hydraulic power steering | ||
| Brake | drum brake | ||
| Working | Hydraulic System | Lifting Capacity at 610 mm Behind Lift Point (kg) | 4.98 |
| Device | 3-Point Suspension | Category:O | |
| P.T.O. Shaft | Rotating Speed (rpm) | 720 | |
| Spline Size | 8-Ø35 or 6-Ø35 Rectangular Spline | ||
| Rated Power (HP) | 60HP |
| Type | Wheel Tractor |
| Place of Origin | Shandong, China |
| Warranty | 1 Year |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 8 months |
| Core Components | Motor, Pressure vessel, Gearbox, Engine |
| Engine Brand | YTO |
| Weight | 5600 KG |
| By wheel | 4WD |
| Use | Farm Tractor |
| Drive Type | Gear Drive |
| Brand Name | Taishan |
| Key Selling Points | Sustainable |
| Product name | Small Farm Tractor |
| Color | Customer Requirements |
| Engine | Chinese Famous Brand |
| Clutch | Dual-stage |
| After Warranty Service | Video technical support |
| Local Service Location | Egypt Australia |
| Packaging and delivery | |
| Packaging Details | In nuder or iron frame |
| Port | Qingdao |
| Selling Units: | Single item |
| Single package size: | 3500X1500X2100 cm |
| Single gross weight: | 1900.000 kg |
| Supply Ability | |
| Supply Ability | 200 Set/Sets per Day |
