| Model | TL904 | |
| Machine parameters | Type | 4*4 |
| Rated Traction( KN) | 17.5 | |
| PTO Max Power (KW) | 56.2 | |
| Dimensions(mm) | 3980*1820*2600 | |
| Wheelbase(mm) | 2050 | |
| Track(mm) | Front wheel(mm) | 1280 |
| Rear wheel(mm) | 1100-1390 | |
| Ground clearance(mm) | Minimum ground clearance(mm) | 330 |
| Minimum turning cricle radius | Use unilateral braking | 4.2±0.30 |
| Not unilateral braking | 4.8±0.30 | |
| Minimum use quality | 3144 | |
| Gearbox | 12F+12R Shuttle Shift | |
| Steering System | hydraulic steering gear | |
| Drive Train | Clutch | double acting clutch |
| Working equipment | Maximum lifting force at 610mm(KN) | ≥7.7 |
| Suspension mechanism | Three-piont suspension type 1 | |
| PTO shaft | PTO Spedd(r/min) | 540/760(option: 540/1000) |
| Tire | Front wheel specifications | 8.3-20/8.3-24 |
| Rear wheel specifications | 12.4-24/12.4-28/14.9-30/11-32 | |
| Engine | Type | Inline, 4 stroke, Water cooled |
| Cylinder | 4 | |
| Optional | Cabin | AC/Heater |
| Roll bar | ||
| Canopy | ||
| Perfusion volume | Radiater(L) | 12 |
| Fuel tank(L) | 64 | |
| Hydraulic steering oil (L) | 0.8 | |
| Steering system oil (L) | 20 | |
| This parameter table is for reference only, everything is based on actual products | ||
| Rated Power (HP) | 90HP |
| Type | Wheel Tractor |
| Place of Origin | Shandong, China |
| Warranty | 2 years |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 2 years |
| Core Components | Motor, Pump, Pressure vessel, Gearbox, Engine, Gear, PLC, Bearing |
| Engine Brand | WEICHAI |
| Weight | 2800 KG |
| By wheel | 4WD |
| Use | Farm Tractor |
| Drive Type | Gear Drive |
| Brand Name | TAVOL |
| Key Selling Points | Multifunctional |
| Horse power | 25-260hp |
| Engine Emission | Euro2/Euro3 |
| Engine type | 4 cylinder |
| Clutch | Dual- Stage Clutch |
| PTO Speed | 540/760 r/min |
| Color | Customer Requirements |
| Dimension(L*W*H) | 3400*1520*1980 |
| Style | Farm Agricultural Tractor |
| Tire | 8.3-20/12.4-28 |
| Differential Lock | Yes |
| Packaging and delivery | |
| Selling Units: | Single item |
| Single package size: | 340X190X200 cm |
| Single gross weight: | 3000.000 kg |
